PR Electronics 5343B Level Transmitter 30V, 85 °C, -40 °C

Name: PR Electronics 5343B Level Transmitter 30V, 85 °C, -40 °C
Brand: PR Electronics
SKU: 7967127
Availability: LimitedAvailability

RS Stock No.: 796-7127Brand: PR ElectronicsManufacturers Part No.: 5343B

View all in Temperature Transmitters

Technical Documents

Specifications

Brand

PR Electronics

Product Type

Level Transmitter

Output Type

Current

Diameter

44mm

Series

5343B

Depth

20.2mm

Maximum Supply Voltage

30V

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

85°C

Hazardous Area Certification

Ex, ATEX

Standards/Approvals

GL V1-7-2, FM 2D5A7, IECEx DEK 13.0036X, EMC 2014/30/EU, ATEX 2014/34/EU KEMA 03ATEX1538, DNV-GL Marine Stand. f. Certific. No. 2.4, EAC TR-CU 020/2011, EAC Ex TR-CU 012/2011 RU C-DK.GB08.V.00410, INMETRO DEKRA 13.0002 X

Country of Origin

Denmark

Product Details

5343 Type - 2-wire Level Transmitter

PR Electronics 5343 is a sensor head-mounted 2-wire programmable level transmitter with high measurement accuracy suitable for measuring liquid levels in a wide range of industry processes. The transmitter can take in potentiometer signals from reed switch chains, which are used for measuring liquid levels – for instance, in a tank. The 5343 level transmitter is programmable via the PR 5909 Loop Link (7967020) and PReset software.

Features and Benefits

• 5343A is the Standard type (stock-no. 827-5432)
• 5343B is the version with ATEX, FM, IECEx & INMETRO (stock-no. 796-7127)
• Potentiometer or Ohmic input
• Programmable sensor error value
• High measurement accuracy
• Unique process calibration function
• User-defined linearization function can be activated
• The transmitter is protected against polarity reversal
• DIN form B sensor head mounting
