Lumel N25 LED Digital Panel Multifunction Meter for Current, Voltage

Name: Lumel N25 LED Digital Panel Multifunction Meter for Current, Voltage
Brand: Lumel
SKU: 1718481
Availability: LimitedAvailability

RS Stock No.: 171-8481Brand: LumelManufacturers Part No.: N25-S250000E0

View all in Multi Function Panel Meters

Technical Documents

Specifications

Brand

Lumel

Product Type

Digital Panel Multifunction Meter

Properties Measured

Current, Voltage

Display Type

LED

Number of Digits

Depth

64mm

Digit Height

14mm

Minimum Operating Temperature

-10°C

Maximum Operating Temperature

55°C

Standards/Approvals

CE Certified

Meter Type

Digital

Series

N25

Minimum Measurement

-66 mV, -11 mV, -11 V, -1 mA, -0.5 V, 3.6 mA

Country of Origin

Poland

Product Details

Indicators of N25 series are destined for measurement of d.c. voltage or d.c. current, temperature from Pt100 sensors and J, K thermocouples, a.c. voltage and a.c. current

5-digit LED display, digits of 14 mm high,
Possible configuration of parameters through the PD14 programmer and the free delivered LPConfig program,
precision of displayed results (decimal point),
measurement averaging time,
recounting of indications (individual characteristic),
automatic or manual compensation: temperature of cold junction for measurements with thermocouples or wire resistance for Pt100 sensors (N25T),
Supply: 85…253 V a.c./d.c. or 20…24 V a.c./d.c., 110 V a.c., 230 V a.c.
Overall dimensions: 96 x 48 x 64 mm

View all in Multi Function Panel Meters

Stock information temporarily unavailable.

€ 187.53

€ 187.53 Each (Exc. VAT)
