Lascar DPM Series Digital Voltmeter DC, LED Display 3.5-Digits 0.1 %, 40 mm, 72 mm
Technical Document
Specifications
Brand
LascarProduct Type
Digital Voltmeter
Current Type
DC
Number of Digits
3.5
Display Type
LED
Cutout Height
40mm
Cutout Width
72mm
Depth
8.4mm
Digit Height
19mm
Meter Accuracy
0.1 %
Minimum Operating Temperature
0°C
Maximum Operating Temperature
50°C
Standards/Approvals
No
Series
DPM
Product details
19mm, 4 Digit Meter
Operating Temperature Range 0 to +50°C.
High contrast red LED display
Single rail supply, suitable for single ended, differential and floating input measurement
Programmable decimal points
Auto zero, auto polarity
Input leakage current 10pA
Dimensions: H39 x W71.5 x D21mm
Panel cut-out: 72 x 40mm
Depth behind panel: 6.5mm
Rated to IP67
Supplied with
IDC ribbon cable connector, plastic bezel and window.
LED, 11 to 19mm Digit Height
All meters have an accuracy of ±0.1% ( ± 1 count).
Stock information temporarily unavailable.
€ 55.37
€ 55.37 Each (Exc. VAT)
1
€ 55.37
€ 55.37 Each (Exc. VAT)
Stock information temporarily unavailable.
1
| Quantity | Unit price |
|---|---|
| 1 - 4 | € 55.37 |
| 5 - 9 | € 53.64 |
| 10+ | € 52.49 |
