Technical Documents
Specifications
Brand
ABBProduct Type
Miniature Circuit Breaker
Number of Poles
1
Current Rating
63A
Tripping Characteristics
Type K
Rated AC Voltage
400V ac
Mount Type
DIN Rail
Breaking Capacity
6kA
Range
System Pro M Compact
Series
S200
Terminal Type
Screw
IP Rating
IP40, IP20
Height
88mm
Depth
69mm
Standards/Approvals
IEC/EN 60947-2, IEC/EN 60898-1
Width
35mm
Better World Product
Yes
Better World Claim
Designed for Disassembly
Reset Actuator Type
Toggle Switch
Tripping Mechanism
Thermomagnetic, Electromagnetic
Country of Origin
Germany
Product Details
This miniature circuit-breaker provides overload and short-circuit protection for single-phase installations on DIN-rail systems. It employs dual thermomagnetic and electromagnetic trip mechanisms to respond appropriately to sustained overloads and instantaneous faults, and is rated for AC systems up to 400 V.
It uses screw-type terminals with a cylinder-lift design permitting flexible and rigid conductors up to 35mm² depending on conductor type and ferrule use.
The contact position is shown by a red ON/green OFF marking to provide a Visual state indication.
It is rated to operate between −25 °C and +55 °C and withstands vibration and shock levels specified for panel-mounted equipment.
It mounts on standard TH35 DIN rails and fits a single modular width of 12.5mm for Compact panel layouts.
Bottom-fitting auxiliary and modular accessories such as auxiliary contacts, shunt trips and undervoltage releases can be fitted to extend functionality.
Stock information temporarily unavailable.
€ 113.25
€ 113.25 Each (Exc. VAT)
1
€ 113.25
€ 113.25 Each (Exc. VAT)
