TE Connectivity Amplimite HD-20 15 Way Right Angle Through Hole D-sub Connector Socket, 2.74mm Pitch, with 4-40 UNC

RS Stock No.: 446-5170PBrand: TE ConnectivityManufacturers Part No.: 5747845-4
brand-logo
View all in D Sub Connectors

Technical Document

Specifications

Brand

TE Connectivity

Number Of Contacts

15

Gender

Female

Body Orientation

Right Angle

Mounting Type

Through Hole

Pitch

2.74mm

Mounting Hardware

4-40 UNC Threaded Inserts, Boardlocks

Termination Method

Solder

Housing Material

Thermoplastic

Length

39.14mm

Width

12.54mm

Depth

18.79mm

Contact Material

Phosphor Bronze

Dimensions

39.14 x 12.54 x 18.79mm

Contact Plating

Gold over Nickel

Series

AMPLIMITE HD-20
