TDK-Lambda Switching Power Supply, NV1-4G5FF-C 4 Output 24V dc, 180 W, Input 90V ac to 264V ac
Technical Document
Specifications
Brand
TDK-LambdaProduct Type
Switching Power Supply
Maximum Output Voltage
24V dc
Number of Outputs
4
Mount Type
Chassis
Power
180W
Minimum Operating Temperature
0°C
Maximum Operating Temperature
70°C
Depth
31.75mm
Length
127mm
Weight
250g
Standards/Approvals
EN 61000-4-3, VCCI-B, IEC/UL/CSA/EN 62368-1, FCC Class B, EN 61000-4-8, EN 61000-4-6, CE, EN 55011, EN 55022-B, EN 61000-4-11, EN 61000-4-2, EN 61000-4-4, EN 61000-4-5
Width
76mm
Maximum Input Voltage
264V ac
Series
NV1
Efficiency
90%
Minimum Input Voltage
90V ac
Hazardous Area Certification
No
Country of Origin
United Kingdom
Product details
175W & 350W Universal Input, Single/Multi Output, NV Power Series
No minimum load required
High power density
Power factor correction to EN61000-3-2
EMC meets EN55022-B
Overvoltage/current/temperature and short circuit protection
Fully regulated outputs
175W versions
Designed for 1U applications
Remote sense; O/P 1 (triple O/Ps), O/Ps 1 & 2 (quad O/Ps)
O/P 1 signal good
Suffix-N types have 'Global Interface Signals'
3mm fixing (2 either side or 4 on base)
350W versions
Integral end mounted fans
Screw terminal inputs
Signals; Module Good, Module Inhibit
4mm fixing (2 either side or 4 on base)
Approvals
UL recognised, CSA certified
Standards
EN60950, CSA22-2-950
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
€ 282.20
€ 282.20 Each (Exc. VAT)
1
€ 282.20
€ 282.20 Each (Exc. VAT)
Stock information temporarily unavailable.
1
| Quantity | Unit price |
|---|---|
| 1 - 4 | € 282.20 |
| 5 - 9 | € 273.72 |
| 10 - 24 | € 265.26 |
| 25 - 49 | € 256.79 |
| 50+ | € 248.33 |
