SMC Electrical Linear Actuator 24V 200mm/s

Name: SMC Electrical Linear Actuator 24V 200mm/s
Brand: SMC
SKU: 6685622
Availability: LimitedAvailability

RS Stock No.: 668-5622Brand: SMCManufacturers Part No.: LDZBB3L-50A3

Image representative of range

Technical Documents

Specifications

Brand

Product Type

Electrical Linear Actuator

Maximum Speed

200mm/s

Series

Voltage

24V

Motor Technology

DC Motor

Maximum Force

196N

IP Rating

IP67

Minimum Operating Temperature

5°C

Spindle Type

Slide Screw

Maximum Operating Temperature

40°C

Standards/Approvals

JIS Class 2, IEC529, IP67, JIS C 0920

Country of Origin

Japan

Product Details

Able to control the stroke with ON/OFF signals. It can be operated like an air cylinder
Simple extension and retraction motion control
Pressure control
Suitable for an environment where an air supply is not available
Two sizes that offer an equivalent thrust to air cylinders of 16 and 25 mm
All cylinders supplied with extra locking nut

Able to control the stroke with ON/OFF signals. It can be operated like an air cylinder
Simple extension and retraction motion control
Pressure control
Suitable for an environment where an air supply is not available
Two sizes that offer an equivalent thrust to air cylinders of 16 and 25 mm
All cylinders supplied with extra locking nut
