Technical Documents
Specifications
Brand
RS ProProduct Type
Base Flange
Sub Type
Type 3
Compatible Strut Profile
Type 3
Structural Element Type
Round Tube
Compatible Tube Size
48.3 mm
Material
Cast Iron
Product System
152
Standards/Approvals
No
Series
RS Handrail System
Product Details
The line drawing illustrates some typical applications of the gradient fittings for the construction of handrails on slopes and ramps between 0° - 11°.
For tube Size Ref. 3 (48.3mm OD tube)
The 'selection guide' table links the alphabetical key in the illustration to the specific fittings (a typical stock number is also quoted).
The 'selection guide' table links the alphabetical key in the illustration to the specific fittings (a typical stock number is also quoted).
BS 1387
Stock information temporarily unavailable.
€ 34.67
€ 34.67 Each (Exc. VAT)
1
€ 34.67
€ 34.67 Each (Exc. VAT)
Stock information temporarily unavailable.
1
| Quantity | Unit price |
|---|---|
| 1 - 4 | € 34.67 |
| 5 - 9 | € 33.98 |
| 10 - 24 | € 33.29 |
| 25+ | € 32.59 |
