Technical Documents
Specifications
Brand
OmronProduct Type
Push Button Switch
Switch Operation
Latching
Illuminated
Yes
Series
A3C
Panel Cutout Size
12 mm
Mount Type
Panel
Contact Configuration
SPST
Terminal Type
Solder
LED Colour
Green, Red, White, Yellow
IP Rating
IP40
Minimum Operating Temperature
-10°C
Contact DC Voltage
30V dc
Contact AC Voltage
24V ac
Actuator Style
Round
Maximum Operating Temperature
55°C
Switch Configuration
On-Off
Standards/Approvals
UL, CE, CSS
Switch Contact Current
500mA
Product Details
Stock information temporarily unavailable.
€ 16.36
€ 16.36 Each (Exc. VAT)
1
€ 16.36
€ 16.36 Each (Exc. VAT)
Stock information temporarily unavailable.
1
| Quantity | Unit price |
|---|---|
| 1 - 4 | € 16.36 |
| 5 - 9 | € 15.87 |
| 10 - 24 | € 15.38 |
| 25 - 49 | € 14.57 |
| 50+ | € 13.41 |
