Technical Documents
Specifications
Brand
LemoNumber of Contacts
4
Product Type
Circular Connector
Mount Type
Cable
Current
10A
Connector Size
11.9 mm
Plug/Socket
Socket
Contact Gender
Female
IP Rating
IP50
Series
1S
Orientation
Straight
Voltage
1800V
Termination Type
Solder
Mating Type
Push Pull
Shell Size
1
Minimum Operating Temperature
-55°C
Maximum Operating Temperature
250°C
Housing Material
Brass
Pole Format
4
Standards/Approvals
No
Contact Plating
Gold, Nickel
Contact Material
Brass Alloy Bronze Alloy
Country of Origin
Switzerland
Product Details
The Lemo 1S series 4-contacts circular connector receptacle has a female socket and male pins solder cup. This cable mount connector has a current rating of up to 10A. This connector features a highly precise push-pull latching system with high durability strain relief collets and in-built keying to prevent mismating. It has a rugged and robust design for every environmental and mechanical requirement in indoor and outdoor applications. It is made from chrome-plated brass with a collet nut and nickel-plated brass latch sleeve. This range offers three sizes of fully populated cable mount plugs and panel/PCB mount sockets with optional collets and strain reliefs to cover a wide range of cable sizes.
S series cylindrical connectors
Series of metal multi-pin connectors with very compact dimensions
Fitted with a push-pull locking system, for great speed of use. Absolute protection against vibration, shock and accidental pulling on the cable
Available in 3 different sizes (0S, 1S and 2S) with different contact layouts
The correct keyway is ensured by an insulating unit (both male and female)
€ 43.88
Each (Exc. VAT)
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
€ 44.06
€ 44.06 Each (Exc. VAT)
1
€ 44.06
€ 44.06 Each (Exc. VAT)
Stock information temporarily unavailable.
1
| Quantity | Unit price |
|---|---|
| 1 - 4 | € 44.06 |
| 5 - 9 | € 42.74 |
| 10 - 19 | € 41.41 |
| 20 - 49 | € 40.09 |
| 50+ | € 37.90 |
