Infineon TLE9350BVSJXTMA1, CAN Transceiver 5 Mbps, 8-Pin PG-DSO-8

Infineon E57G General purpose Series CAN Transceiver, 5 Mbps Maximum Data Rate, 6V Minimum Supply Voltage - TLE9350BVSJXTMA1

This CAN transceiver is a general-purpose interface device designed for automotive CAN bus networks. It functions as a single-node transceiver in an 8-pin PG-DSO-8 package and is intended to facilitate high-speed data exchange between controllers and the physical CAN bus in vehicle systems. The component supports recognised automotive communication standards and includes protective features suited to electrically noisy environments.

Features and Benefits:

• Supports 5Mbps data throughput for fast network communication
  Complies with ISO11898-2:2016 for physical-layer interoperability
  Meets SAE J2284-4/-5 to fit automotive CAN requirements
  Built-in ESD protection enhances resilience against transients
  Power-down mode reduces supply current when inactive
  Operates across supply limits from 6V to -0.3V for safety margins

Applications

• Suitable for in-vehicle high-speed CAN links
  Ideal for gateway and ECU communication modules
  Used with diagnostic interfaces requiring fast transfer
  Can be used for body electronics network nodes
  Suitable for development boards needing a single transceiver

How many transceivers are included on the device?

It provides a single transceiver channel intended for one CAN node.

What package should designers plan for on the PCB?

The device is supplied in an 8-pin PG-DSO-8 package compatible with surface-mount layouts.

What protection features guard the interface from electrical stress?

The device incorporates electrostatic discharge protection to mitigate damage from electrical transients.

How does the unit behave when not actively communicating?

A power-down mode is available to lower supply current during idle periods.
