Festo Clamp

Festo Clamping Piece - EV Series - EV-20/180-5

The flat and compact design of this clamping module from Festo means it can be used in confined areas to firmly hold workpieces in place. The hydraulically actuated clamp offers consistency and accuracy by eliminating the need for manual handling. It has a clamping force that can be adjusted to suit different applications and a controlled gripping strength to increase both the safety and efficiency of machining operations. The unit is hermetically sealed, so it's suitable for use in harsh and dusty environments.

Features and Benefits

• Block shape clamping piece
• Die-cast aluminium housing
• Operating pressure range of 2 bar to 6 bar
• M5 pneumatic connection
• Stroke size of 5 mm
• Clamping area of 20 mm x 180 mm
• Pressure chamber equipped with a diaphragm
• Through-hole mount type
• Can be assembled in any position
• Ambient temperature range of -20°C to +40°C

Range Information

• Clamping modules from Festo's EV series have a maximum operating pressure of 6 bar
• Units are designed as either round or block-shaped
• Choose from a variety of mounting accessories and attachments, for example, pressure plates to protect the units' diaphragms from external damage
• All the units are single-acting and include a reset function

Certifications

• ISO8573-1:2010
