Bulgin Circular Connector, 2 Contacts, Flange, Standard Connector, Plug, Male, IP68, PX0941 Series

Bulgin Buccaneer 900 Series Circular Connector, 2 Contacts, IP68 - PX0941/02/P

This flange mount connector falls under the category of circular power connectors and features a robust design suited for demanding environments. Incorporating a male plug with two contacts, it ensures secure electrical connections in both industrial and automation applications. The connector is constructed from polyamide and is rated IP68, guaranteeing water and dust resistance when mated.

Features & Benefits

• Provides superior water and dust protection with an IP68 rating
• Positive locking mechanism for reliable and secure connections
• Operating temperature range from -40°C to +85°C for diverse requirements
• Supplied with high-grade sealing gaskets for enhanced durability

Applications

• Used in automation systems for secure connections
• Suitable for electrical and mechanical equipment installations
• Integrated into harsh environments requiring dust and water protection
• Ideal for connecting power supplies in industrial machinery

What are the cable accommodation specifications for this connector?

This connector can accommodate cable sizes ranging from 10AWG to 14AWG, or 2.5mm² to 4mm². This versatility assists in various connection requirements based on specific applications.

How does the locking mechanism contribute to reliability?

The positive fast-acting locking ring allows for a secure connection that maintains physical integrity under movement or vibration, making it suitable for dynamic installations and environments.

Is additional equipment needed to maintain its IP68 rating?

To maintain the IP68 rating when not in use, a sealing cap is available separately. This ensures the connector is protected from environmental factors when unmated.

What types of applications can benefit from a threaded mating type?

Threaded mating types provide enhanced stability, making them ideal for environments where connections may experience vibration or tension, such as in machinery or vehicles.

Can this connector be mounted at an angle?

Yes, an additional bulkhead adaptor moulding is available separately, allowing this connector to be angled at either 45 or 90 degrees for versatile installation options.

Approvals

UL; VDE
