BK Precision Digital Bench Power Supply, 1-Output 0 V ac to 60V, 350 W, 10 A Max

B&K Precision Model 1747 General Purpose Dual Range DC Power Source

B&K Precision model 1747 is a general purpose dual range DC power source. It can output higher voltage at a lower current range or more current at a lower voltage range. Two 4-digit LED displays continuously monitor the output voltage and current. The power supply can be operated locally from the front panel or remotely through the RS-232 interface. The 1747 has excellent regulation and low ripple characteristics. Its mechanical configuration conserves bench space and facilitates portability. It is well-suited for a wide variety of electrical and electronics applications in service shops, engineering laboratories, production, school laboratories and the home.

• Low ripple and noise
• Excellent regulation
• Constant voltage (CV) and constant current (CC) operation
• Two large, easy-to-read LED displays provide good visibility in bright or low light
• LED indication for CV and CC modes
• Automatic recall of last settings on power up
• RS-232 Interface
• Isolated output
• Overload protection
• Reverse polarity protection

B&K Precision

Supplied with

Power cord, instruction manual, RS-232 cable, shorting bar
