Technical Documents
Specifications
Brand
ApemProduct Type
Toggle Switch
Contact Configuration
DPDT
Switch Operation
On-On
Switch Contact Current
4A
Mount Type
Panel
Terminal Type
Solder Lug
Illuminated
No
Panel Cutout Size
6.5 mm
Minimum Operating Temperature
-40°C
Contact DC Voltage
24V dc
Contact AC Voltage
250V ac
Actuator Length
14.75mm
Actuator Material
Nickel Plated Brass
Maximum Operating Temperature
85°C
Switch Configuration
On-On
Height
36mm
Length
14mm
Standards/Approvals
UL, RoHS, NFVDE, CSA, CECC
Width
12mm
Series
5000
Mechanical Life
100000Cycles
Country of Origin
France
Product Details
For biased switches '(on)' refers to momentary 'on' position
UL; CSA; CECC; LNZ; GAM T1; QPL (Europe); MUAHAG; NATO
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
€ 29.47
€ 29.47 Each (Exc. VAT)
1
€ 29.47
€ 29.47 Each (Exc. VAT)
Stock information temporarily unavailable.
1
| Quantity | Unit price |
|---|---|
| 1 - 24 | € 29.47 |
| 25 - 49 | € 24.16 |
| 50 - 99 | € 22.09 |
| 100 - 249 | € 20.63 |
| 250+ | € 18.86 |
