Technical Documents
Specifications
Brand
Alpha WireNumber of Pairs
2
Product Type
Data Cable
Cross Sectional Area
0.35 mm²
Cable Length
50m
Jacket Colour
Grey
Outside Diameter
6.58mm
Jacket Material
Polyvinyl Chloride
Minimum Operating Temperature
-30°C
Maximum Operating Temperature
105°C
Standards/Approvals
CE, CSA Certified, UL
Conductor Material
Tin Copper Wire
Series
Pro-Tekt
Voltage
300V
Size of Strands
30AWG
Fire Behaviour
Flame Retardant
Number of Strands
7
Core Strands
7 x 30AWG
Product Details
This data cable is expertly engineered for high-performance applications. Designed by Belden, it features a length of 50 m, with a twisted pair configuration that ensures reliable signal transmission. The outer diameter of 6.58 mm and PVC sheath material make it both durable and flexible for various installation needs.
The cable's flame retardant characteristics, along with a wide operating temperature range from -30°C to +105°C, make it capable of enduring harsh conditions while maintaining performance.
The screened design utilises A/P/A tape shielding, significantly reducing the effects of electromagnetic interference, which is essential for maintaining data integrity in complex systems.
It can withstand a maximum pull tension of 14 kg, ensuring it can be safely installed without compromising performance.
The twisted pair construction minimises crosstalk and ensures high-quality signal transmission, making it ideal for data communication purposes.
The PVC sheath provides excellent resistance to environmental conditions, enhancing the cables longevity and making it suitable for a range of applications.
Stock information temporarily unavailable.
€ 190.65
€ 190.65 1 Reel of 50 Metres (Exc. VAT)
1
€ 190.65
€ 190.65 1 Reel of 50 Metres (Exc. VAT)
Stock information temporarily unavailable.
1
