Technical Documents
Specifications
Brand
Alpha WireNumber of Pairs
2
Product Type
Data Cable
Cross Sectional Area
0.23 mm²
Number of Cores
4
Cable Length
100m
Jacket Colour
Grey
Outside Diameter
6.07mm
Minimum Operating Temperature
-30°C
Jacket Material
Polyvinyl Chloride
Maximum Operating Temperature
105°C
Standards/Approvals
CE, CSA Certified, UL
Number of Strands
7
Core Strands
7 x 32AWG
Size of Strands
32AWG
Fire Behaviour
Flame Retardant
Conductor Material
Tin Copper Wire
Series
Pro-Tekt
Voltage
300V
Product Details
This data cable is a robust solution designed for a variety of electronic applications, particularly in automation and mechanical industries. Featuring a twisted pair cable construction, it incorporates two pairs of 24 AWG wires cabled together and is screened to minimise electromagnetic interference. With a length of 50 m, this PVC-sheathed cable has an outer diameter of 6.07 mm, ensuring flexibility while maintaining structural integrity.
The cable is insulated with semi-rigid PVC, which offers protective properties while maintaining flexibility, ideal for various installations.
It functions effectively within a temperature range of -30°C to +105°C, making it suitable for both extreme cold and heat situations.
The screened design significantly reduces potential interference from external sources, enhancing the reliability and quality of the data transmission.
While it has sunlight resistance, it is primarily designed for indoor use; therefore, additional protection may be required for prolonged outdoor exposure.
Stock information temporarily unavailable.
€ 279.81
€ 279.81 1 Reel of 100 Metres (Exc. VAT)
1
€ 279.81
€ 279.81 1 Reel of 100 Metres (Exc. VAT)
Stock information temporarily unavailable.
1
