Alpha Wire Ecogen Ecowire Series Slate 3.3 mm² Hook Up Wire, 12 AWG, 65 x 0.25 mm, 0.25 mm core strands, 30 m, Modified

Belden Ecogen Ecowire Series Hook Up Wire, 3.3mm² Cross Sectional Area, Red Jacket - 6718 RD001

This hook-up wire is a flexible electrical conductor designed for signal and power connections in industrial and automotive systems. It features a red outer sheath and is intended for use where halogen-free, low-smoke behaviour and elevated temperature endurance are required. The construction suits environments demanding reliable insulation and mechanical flexibility.

Features & Benefits

• 65-strand copper core provides enhanced flexibility and vibration resistance
  3.3mm² cross section delivers substantial current capacity in Compact routing
  Rated for 600V to support medium-voltage internal wiring applications
  Maximum operating temperature of 105°C allows use near heat sources
  Minimum operating temperature of -40°C maintains pliability in cold conditions
  Zero halogen and low smoke characteristics reduce toxic emissions in fires

**Applications**

• Suitable for wiring in control cabinets within automation plants
  Ideal for internal harnessing in commercial vehicles complying with thin-wall specs
  Used for interconnections on industrial machinery and panel builds
  Can be used for retrofit installations where space-saving conductors are needed

What conductor construction gives the cable its flexibility?

It uses a multi-strand copper core comprising 65 fine strands to improve bend performance and resistance to metal fatigue in dynamic installations.

Which materials form the cable jacket and what do they provide?

The covering combines modified polyphenylene ether with PVC to balance thermal endurance, dimensional stability and mechanical protection under typical industrial conditions.

What fire-performance ratings does it meet for safety-sensitive locations?

It conforms to zero halogen requirements and exhibits low smoke output, and meets test standards for FT1 and VW-1 flame performance to limit flame propagation.

Are there industry approvals verifying suitability for automotive thin-wall applications?

It is compliant with ISO 6722 classifications for thin and ultra-thin wall automotive wiring, indicating suitability for modern vehicle harnesses.

What labelling or regulatory standards apply to its use in professional installations?

The product is manufactured to meet recognised approvals including UL AWM 11028 and CSA AWM I A/B FT1 as well as CE, RoHS and REACH regulatory criteria.

Standards

UL AWM 11028 VW-1, CSA AWM I A/B FT1, RoHS/RoHS2 Compliant, IEC 60332-2 Flame Behavior, REACH Compliant, CE Compliant
