ABB JSHD Series Safety Enabling Switch, 3 Position, IP65

ABB JSHD Series Safety Enabling Switch, 1NO + 1NC Contact Configuration, 500 mA Supply Current - 2TLA020001R1000 JSHD2C type E

This safety enabling switch is designed for enhanced operational safety in automation and industrial applications. Offering a compact size, it measures 26.55mm in length and width, and has a slim depth of 13.5mm. The product is made from durable nylon 66 housing and features an IP65 rating, ensuring protection against dust and water ingress.

Features & Benefits

• 1NO + 1NC contact configuration enables versatile control
• Supports a supply current of 500 mA for reliable operation
• IP65 rated for protection against water and dust
• Constructed with nylon 66 housing for robust durability
• Designed to ensure safety during emergency stop procedures
• Compact dimensions facilitate easy installation in tight spaces

Applications

• Utilised in industrial automation systems for safety measures
• Ideal for equipment where rapid shut-off is essential
• Employed in machinery requiring emergency stop functions
• Suitable for use in environments where water and dust exposure is likely

What is the maximum current supported by the switch?

The maximum current that can be handled is 0.002A, making it suitable for low-power applications.

How does the contact configuration impact functionality?

The 1NO + 1NC configuration allows for both normally open and normally closed functions, providing flexibility in circuit design and control.

What material is the housing made from, and why is it significant?

The housing is made from nylon 66, which offers enhanced strength and resistance to harsh environmental conditions, ensuring longevity and reliability.

How does the IP65 rating benefit the switch in operational environments?

The IP65 rating indicates that the switch is completely dust-tight and can withstand water jets, making it ideal for challenging industrial environments.
