ABB System Pro M Compact S200M Miniature Circuit Breaker, 2-Pole, 63 A, Type D, 400 V ac AC, 125 V dc DC, 15 kA Breaking
Technical Document
Specifications
Brand
ABBNumber of Poles
2
Product Type
Miniature Circuit Breaker
Current Rating
63 A
Tripping Characteristics
Type D
Rated AC Voltage
400 V ac
Rated DC Voltage
125 V dc
Breaking Capacity
15kA
Mount Type
DIN Rail
Range
System Pro M Compact
Series
S200M
Terminal Type
Screw
IP Rating
IP20
Width
35 mm
Height
88mm
Depth
69mm
Standards/Approvals
IEC/EN 60898-1, IEC/EN 60947-2
Reset Actuator Type
Lever
Tripping Mechanism
Thermal, Electromechanic
Country of Origin
Germany
Product details
Type D Double Pole 10kA - System Pro M Compact
The System Pro M Compact range of Miniture Circuit Breakers from ABB, for use in Residential, Commercial and Industrial applications with a tripping characteristic of Type D
ABB System Pro M Single & Double Pole MCB's
Stock information temporarily unavailable.
€ 75.80
€ 75.80 Each (Exc. VAT)
1
€ 75.80
€ 75.80 Each (Exc. VAT)
Stock information temporarily unavailable.
1
