Vishay P-Channel MOSFET, 12 A, 100 V, 3-Pin TO-220AB IRF9530PBF
Technical Document
Specifications
Brand
VishayChannel Type
P
Maximum Continuous Drain Current
12 A
Maximum Drain Source Voltage
100 V
Package Type
TO-220AB
Mounting Type
Through Hole
Pin Count
3
Maximum Drain Source Resistance
300 mΩ
Channel Mode
Enhancement
Minimum Gate Threshold Voltage
2V
Maximum Power Dissipation
88 W
Transistor Configuration
Single
Maximum Gate Source Voltage
-20 V, +20 V
Width
4.7mm
Transistor Material
Si
Number of Elements per Chip
1
Length
10.41mm
Typical Gate Charge @ Vgs
38 nC @ 10 V
Maximum Operating Temperature
+175 °C
Height
9.01mm
Minimum Operating Temperature
-55 °C
Country of Origin
China
Product details
P-Channel MOSFET, 100V to 400V, Vishay Semiconductor
MOSFET Transistors, Vishay Semiconductor
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
€ 50.12
€ 1.002 Each (In a Tube of 50) (Exc. VAT)
50
€ 50.12
€ 1.002 Each (In a Tube of 50) (Exc. VAT)
Stock information temporarily unavailable.
50
Stock information temporarily unavailable.
| Quantity | Unit price | Per Tube |
|---|---|---|
| 50 - 50 | € 1.002 | € 50.12 |
| 100 - 200 | € 0.952 | € 47.62 |
| 250+ | € 0.901 | € 45.06 |
