Vishay P-Channel MOSFET, 6.8 A, 100 V, 3-Pin TO-220AB IRF9520PBF
Technical Document
Specifications
Brand
VishayChannel Type
P
Maximum Continuous Drain Current
6.8 A
Maximum Drain Source Voltage
100 V
Package Type
TO-220AB
Mounting Type
Through Hole
Pin Count
3
Maximum Drain Source Resistance
600 mΩ
Channel Mode
Enhancement
Minimum Gate Threshold Voltage
2V
Maximum Power Dissipation
60 W
Transistor Configuration
Single
Maximum Gate Source Voltage
-20 V, +20 V
Length
10.41mm
Maximum Operating Temperature
+175 °C
Typical Gate Charge @ Vgs
18 nC @ 10 V
Width
4.7mm
Transistor Material
Si
Number of Elements per Chip
1
Height
9.01mm
Minimum Operating Temperature
-55 °C
Country of Origin
China
Product details
P-Channel MOSFET, 100V to 400V, Vishay Semiconductor
MOSFET Transistors, Vishay Semiconductor
