Vishay 1000V 1.5A, Silicon Junction Diode, 2-Pin DO-204AP BYV96E

RS Stock No.: 168-5731Brand: VishayManufacturers Part No.: BYV96E
brand-logo
View all in Schottky Diodes & Rectifiers

Technical Document

Specifications

Brand

Vishay

Mounting Type

Through Hole

Package Type

DO-204AP

Maximum Continuous Forward Current

1.5A

Peak Reverse Repetitive Voltage

1000V

Diode Configuration

Single

Rectifier Type

Switching

Diode Type

Silicon Junction

Pin Count

2

Maximum Forward Voltage Drop

1.6V

Number of Elements per Chip

1

Peak Reverse Recovery Time

300ns

Peak Non-Repetitive Forward Surge Current

35A
