Technical Document
Specifications
Brand
Texas InstrumentsLogic Family
Translator
Product Type
Voltage Level Shifter
Direction Type
Bi-Directional
Maximum Propagation Delay Time @ CL
4ns
Mount Type
Surface
Package Type
SOIC
Number of Elements per Chip
2
Pin Count
14
Output Type
3 State
Logic Function
Voltage Level Translator
Maximum Low Level Output Current
0.02mA
Minimum Supply Voltage
1.2V
Maximum High Level Output Current
-0.02mA
Translation
Voltage Level
Maximum Supply Voltage
5.5V
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
85°C
Height
1.58mm
Length
8.65mm
Standards/Approvals
No
Series
TXB0104
Automotive Standard
No
Product details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
£ 59.30
£ 1.186 Each (In a Tube of 50) (Exc. VAT)
50
£ 59.30
£ 1.186 Each (In a Tube of 50) (Exc. VAT)
Stock information temporarily unavailable.
50
| Quantity | Unit price | Per Tube |
|---|---|---|
| 50 - 50 | £ 1.186 | £ 59.30 |
| 100 - 200 | £ 0.949 | £ 47.45 |
| 250 - 450 | £ 0.89 | £ 44.50 |
| 500 - 700 | £ 0.849 | £ 42.45 |
| 750+ | £ 0.828 | £ 41.40 |
