Texas Instruments TPS77533D, LDO Regulator, 500mA, 3.3 V, ±2% 8-Pin, SOIC
Technical Document
Specifications
Brand
Texas InstrumentsMaximum Output Current
500mA
Number of Outputs
1
Output Voltage
3.3 V
Line Regulation
0.01 %/V
Load Regulation
3 mV
Accuracy
±2%
Mounting Type
Surface Mount
Polarity
Positive
Quiescent Current
0.085mA
Package Type
SOIC
Pin Count
8
Output Type
Fixed
Power Rating
0.904W
Dimensions
4.9 x 3.91 x 1.58mm
Maximum Input Voltage
10 V
Minimum Operating Temperature
-40 °C
Height
1.58mm
Minimum Input Voltage
2.7 V
Maximum Operating Temperature
+125 °C
Width
3.91mm
Length
4.9mm
Product details
LDO (Low Dropout) Linear Voltage Regulators, 500mA, Texas Instruments
LDO (Low Dropout) Linear Voltage Regulators, Texas Instruments
A range of Texas Instruments Low Dropout (LDO) Linear Voltage regulators. LDO voltage regulators are able to operate with a small input-output differential making them suitable for a variety of applications where conventional regulators would be unsatisfactory. The latest generation of LDO regulators offers low quiescent current levels and reduced output noise together with excellent line voltage regulation and high PSRR.
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
Price on asking
Each (In a Pack of 5) (Exc. VAT)
Standard
5
Price on asking
Each (In a Pack of 5) (Exc. VAT)
Stock information temporarily unavailable.
Standard
5
