TE Connectivity FASTON .250 Black Uninsulated Female Spade Connector, Crimp, 6.35 x 0.81 mm Tab Size 14 AWG to 10 AWG
Technical Document
Specifications
Brand
TE ConnectivityProduct Type
Spade Connector
Termination Type
Crimp
Gender
Female
Tab Width
6.35mm
Tab Thickness
0.81mm
Tab Size
6.35 x 0.81 mm
Insulation
Uninsulated
Maximum Wire Size AWG
10 AWG
Minimum Wire Size AWG
14 AWG
Colour
Black
Contact Material
Brass
Contact Plating
Tin
Orientation
Straight
Standards/Approvals
No
Overall Length
19.56mm
Series
FASTON .250
Product details
TE Connectivity FASTON 250 Series Piggyback Crimp Terminals
FASTON 250 series piggyback crimp receptacle tab combination terminals designed for quick and efficient connection and reliability. These FASTON 250 piggyback receptacle terminals have a step down insulation support barrel to compensate for insulation thickness enabling the axial alignment of conductor strands to be maintained. Tapering walls at the rear of these FASTON 250 piggyback receptacle crimp terminals prevent over insertion of shoulderless tabs. The "F" style crimp terminations of these FASTON 250 series quick connect piggyback receptacle tab combinations enable stable electrical and mechanical performance as well as resistance to vibration and corrosion.
