SICK Capacitive Threaded Barrel Proximity Sensor, M30, 25 mm Detection, 2-Wire NO/NC, 20 → 250 V ac
Technical Document
Specifications
Brand
SickThread Size
M30
Sensor Technology
Capacitive
Body Style
Threaded Barrel
Detection Range
25 mm
Output Function
NO/NC
Digital Switching Output Type
2-Wire
Cable Length
2m
Connection Type
Pre-Cabled
Supply Voltage
20 → 250 V ac
IP Rating
IP67
Length
75.6mm
Mounting Type
Non-Flush
Housing Material
PBT
Minimum Operating Temperature
-25°C
Maximum ac Voltage
250V
Shielding
Unshielded
Maximum Switching Frequency
10Hz
Switching Current
500 mA
Reverse Polarity Protection
Yes
Switching Frequency
10 Hz
Series
CM
Maximum Operating Temperature
+80°C
Country of Origin
Lithuania
Product details
Sick CM Series Capacitive Proximity Sensors
Sick CM series capacitive proximity sensors offers high electromagnetic compatibility (EMC), which prevents switching errors. Sensitivity adjustment can be performed quickly and easily using a potentiometer or teach-in button, saving valuable time during commissioning. Sensors installed in inaccessible locations can be equipped with an external, cabled teach-in button.
The CM capacitive proximity sensors feature high shock and vibration resistance and minimal sensitivity to dust and moisture. Together with optical adjustment indicators, these features ensure reliable object detection, in turn ensuring reduced machine downtime.
Plastic body
DC four-wire with PNP normally open and normally closed outputs
Extended sensing range with adjustable sensitivity
Short circuit and reverse polarity protection
Output status LED indication
High EMC immunity
Output type NO/NC
