RS PRO AAP100L4B AC Motor, 3 kW, IE3, 3 Phase, 4-Pole, 400V, Foot Mounting

RS Stock No.: 187-9875Brand: RS PRO
brand-logo
View all in AC Motors

Technical Document

Specifications

Brand

RS Pro

Power Rating

3kW

Product Type

AC Motor

Efficiency Class

IE3

Sub Type

Squirrel Cage Motor

Supply Voltage

400V

Number of Phases

3

Output Speed

1430rpm

Number of Poles

4

Mount Type

Foot

Shaft Diameter

28mm

Material

Aluminium

Shaft Length

60mm

Depth

261mm

Length

329mm

Standards/Approvals

RoHS

Width

261mm

Maximum Output Torque

20.1Nm

Current Rating

6.98A

Series

AAP100L4B

Bearing Type

Deep Groove

Country of Origin

Turkey
