Pepperl + Fuchs NBN15-30GM50-E0 Threaded Barrel Proximity Sensor, M30 NPN NBN40-U1-E0 36V 100 mm 36 V dc 200mA
Technical Document
Specifications
Brand
Pepperl + FuchsThread Size
M30
Product Type
Proximity Sensor
Body Style
Threaded Barrel
Length
2m
IP Rating
IP68
Mount Type
Non-Flush
Width
30mm
Maximum Supply Voltage
36V
Housing Material
Brass White Bronze Coated
Maximum Detection
100mm
Minimum Operating Temperature
-40°C
Maximum DC Voltage
36V dc
Maximum Operating Temperature
85°C
Standards/Approvals
DNV GL rules for classification - Ships
Depth
30mm
Maximum Switching Frequency
1.15kHz
Shielding
Shielded
Series
NBN40-U1-E0
Switching Current
200mA
Output Type
NPN
Country of Origin
Indonesia
Product details
Extended Sensing Range
These Pepperl + Fuchs inductive proximity sensors are cylindrical in design and are available with an extended sensing range of up to 30mm to suit a number of different applications.
Features and benefits
LED indication
Embeddable or flush installation
IP67
Supply voltage 10 to 30Vdc
Short circuit and reverse polarity protection
Pre-wired types have 2m PVC cable
Plug-in types have M12 type V1 connector
Pepperl + Fuchs
