Panasonic ERJ6RQ 1Ω, 0805 (2012M) Thick Film SMD Resistor ±1% 0.125W
Technical Document
Specifications
Brand
PanasonicResistance
1Ω
Technology
Thick Film
Package/Case
0805 (2012M)
Tolerance
±1%
Power Rating
0.125W
Temperature Coefficient
±200ppm/°C
Automotive Standard
AEC-Q200
Series
ERJ6RQ
Minimum Operating Temperature
-55°C
Maximum Operating Temperature
+125°C
Country of Origin
Japan
Product details
0805 Format low Ohmic Resistor - 0.125W
Panasonic ERJ 6R chip resistors are lightweight and compact. Offering high reliability, these chip resistors are constructed from three layers of electrodes and a metal glaze thick film resistive element.
Low-resistance tolerance
Both reflow and flow soldering can be used
Suitable for use with placement machines
AEC-Q200 qualified
Applications
These chip resistors are AEC-Q200 qualified and are suitable for automotive applications.
Standards
IEC 60115-8, JIS C 5201-8, EIAK RC-2134B
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
€ 0.90
€ 0.18 Each (In a Pack of 5) (Exc. VAT)
Standard
5
€ 0.90
€ 0.18 Each (In a Pack of 5) (Exc. VAT)
Stock information temporarily unavailable.
Standard
5
Stock information temporarily unavailable.
