Panasonic 47μF Aluminium Electrolytic Capacitor 400V dc, Radial, Through Hole - EEUED2G470
Technical Document
Specifications
Brand
PanasonicCapacitance
47µF
Voltage
400V dc
Mounting Type
Radial, Through Hole
Technology
Aluminium Electrolytic
Dimensions
16 (Dia.) x 25mm
Height
25mm
Minimum Operating Temperature
-25°C
Diameter
16mm
Maximum Operating Temperature
+105°C
Lifetime
10000h
Lead Pitch
7.5mm
Polarised
Polar
Ripple Current
840mA
Series
ED RADIAL
Tolerance
±20%
Product details
ED Series
Panasonic ED Series Type A electrolytic capacitors feature endurance of 8000 hours to 10000 hours at +105°C (depending on case size). At high frequency, these radial capacitors offer high ripple current.
Low profile options available with a height of 20 mm
Applications
Panasonic ED Series Type V radial capacitors are suitable for use in power supply input circuits and electronic ballast.
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
€ 8.49
€ 1.699 Each (In a Pack of 5) (Exc. VAT)
Standard
5
€ 8.49
€ 1.699 Each (In a Pack of 5) (Exc. VAT)
Stock information temporarily unavailable.
Standard
5
| Quantity | Unit price | Per Pack |
|---|---|---|
| 5 - 20 | € 1.699 | € 8.50 |
| 25 - 45 | € 1.596 | € 7.98 |
| 50 - 95 | € 1.493 | € 7.47 |
| 100 - 245 | € 1.393 | € 6.96 |
| 250+ | € 1.265 | € 6.33 |
