Panasonic 3.3μF Aluminium Electrolytic Capacitor 450V dc, Radial, Through Hole - ECA2WHG3R3
Technical Document
Specifications
Brand
PanasonicCapacitance
3.3µF
Voltage
450V dc
Mounting Type
Radial, Through Hole
Technology
Aluminium Electrolytic
Dimensions
10 (Dia.) x 16mm
Height
16mm
Minimum Operating Temperature
-25°C
Diameter
10mm
Maximum Operating Temperature
+105°C
Lead Pitch
5mm
Lifetime
2000h
Tolerance
±20%
Polarised
Polar
Ripple Current
41mA
Series
NHG
Product details
NHG Series
Panasonic NHG Type A electrolytic capacitors feature endurance of 1000 to 2000 hours at +105°C (dependent on case size). These radial capacitors offer a compact solution in comparison to the NHE Series.
Radial lead type
High reliability
Long life
Low impedance
High ripple current
Applications
Panasonic NHG Series Type A electrolytic capacitors are ideal for use in industrial instruments due to their high reliability.
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
€ 3.17
€ 0.634 Each (In a Pack of 5) (Exc. VAT)
Standard
5
€ 3.17
€ 0.634 Each (In a Pack of 5) (Exc. VAT)
Stock information temporarily unavailable.
Standard
5
Stock information temporarily unavailable.
| Quantity | Unit price | Per Pack |
|---|---|---|
| 5 - 45 | € 0.634 | € 3.17 |
| 50 - 245 | € 0.596 | € 2.98 |
| 250 - 495 | € 0.559 | € 2.80 |
| 500 - 1245 | € 0.509 | € 2.55 |
| 1250+ | € 0.443 | € 2.22 |
