onsemi MJE2955TG PNP Transistor, -10 A, -60 V, 3-Pin TO-220AB
Technical Document
Specifications
Brand
onsemiTransistor Type
PNP
Maximum DC Collector Current
-10 A
Maximum Collector Emitter Voltage
-60 V
Package Type
TO-220AB
Mounting Type
Through Hole
Maximum Power Dissipation
75 W
Minimum DC Current Gain
20
Transistor Configuration
Single
Maximum Collector Base Voltage
70 V
Maximum Emitter Base Voltage
5 V
Maximum Operating Frequency
2 MHz
Pin Count
3
Number of Elements per Chip
1
Dimensions
9.28 x 10.28 x 4.82mm
Maximum Operating Temperature
+150 °C
Product details
PNP Power Transistors, ON Semiconductor
Standards
Manufacturer Part Nos with NSV prefix are automotive qualified to AEC-Q101 standard.
