onsemi 60 V 4 A Diode Schottky 2-Pin DO-214AA MBRS360T3G
Technical Document
Specifications
Brand
onsemiProduct Type
Diode
Mount Type
Surface
Package Type
DO-214AA
Maximum Continuous Forward Current If
4A
Peak Reverse Repetitive Voltage Vrrm
60V
Diode Configuration
Single
Rectifier Type
Schottky
Pin Count
2
Peak Reverse Current Ir
150μA
Minimum Operating Temperature
-65°C
Peak Non-Repetitive Forward Surge Current Ifsm
125A
Maximum Forward Voltage Vf
740mV
Maximum Operating Temperature
175°C
Width
5.84 mm
Height
2.13mm
Length
6.86mm
Standards/Approvals
No
Automotive Standard
AEC-Q101
Product details
ON Semiconductor Schottky Barrier Diodes
This ON Semiconductor Schottky power rectifier employs the Schottky barrier principle using a barrier metal to create the best forward voltage drop−reverse current exchange. Suitable for low voltage, high-frequency rectification as well as a freewheeling and polarity protection diode in a range of surface mount applications wherever a more compact size and weight are key.
• Pb-Free
• Designed for Optimal Automated Board Assembly
• Stress protection guarding
• Epoxy Moulded Case
• Lightweight 11.7mg package
Standards
Products with NSV-, SBR- or S-prefixed Manufacturer Part Nos are AEC-Q101 automotive qualified.
