Omron Simulated Roller Lever Micro Switch, Solder Terminal, 5 A @ 250 V ac, SPDT, IP40
Technical Document
Specifications
Brand
OmronActuator Type
Simulated Roller Lever
Terminal Type
Solder
Contact Current Rating
5 A @ 250 V ac
Contact Configuration
SPDT
IP Rating
IP40
Operating Force
0.59 N
Minimum Operating Temperature
-25°C
Maximum Operating Temperature
+80°C
Contact Material
Silver Alloy
Mechanical Life
50000000Operations
Release Force
0.04N
Operating Temperature Range
-25 → +80°C
Country of Origin
Japan
Product details
Omron Miniature - Low Operating Force
Compact basic switch with an ultra low operating force
Ultra low operating force
V3 style housing
RoHS compliant
Contact rating: 5A @ 250Vac resistive
Contact configuration: SPDT
Solder/Quick - Connect terminals (#187)
Approvals
Approvals: UL, CSA, VDE, TUV, SEMKO
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
Please check again later.
€ 5.25
Each (Exc. Vat)
Standard
1
€ 5.25
Each (Exc. Vat)
Standard
1
Buy in bulk
| Quantity | Unit price |
|---|---|
| 1 - 49 | € 5.25 |
| 50 - 149 | € 4.64 |
| 150 - 249 | € 3.24 |
| 250 - 499 | € 2.88 |
| 500+ | € 2.64 |
