Technical Document
Specifications
Brand
NexperiaMounting Type
Surface Mount
Timer Type
Programmable
Package Type
SOIC
Number of Internal Timers
1
Pin Count
14
Maximum Input Frequency
36MHz
Minimum Operating Supply Voltage
3 V
Maximum Operating Supply Voltage
15 V
Minimum Operating Temperature
-40 °C
Maximum Operating Temperature
+85 °C
Maximum Low Level Output Current
4.2mA
Maximum High Level Output Current
-4.2mA
Maximum Propagation Delay Time @ Maximum CL
1150 ns@ 5 V
Dimensions
8.75 x 4 x 1.45mm
Height
1.45mm
Length
8.75mm
Width
4mm
Country of Origin
Thailand
Product details
4000 Series Multivibrators & Timers, Nexperia
4000 CMOS Logic Family, Nexperia
Stock information temporarily unavailable.
Please check again later.
€ 0.712
Each (In a Pack of 10) (Exc. Vat)
10
€ 0.712
Each (In a Pack of 10) (Exc. Vat)
10
Buy in bulk
Quantity | Unit price | Per Pack |
---|---|---|
10 - 10 | € 0.712 | € 7.12 |
20 - 40 | € 0.406 | € 4.06 |
50 - 90 | € 0.386 | € 3.86 |
100 - 190 | € 0.277 | € 2.77 |
200+ | € 0.26 | € 2.60 |
