Nexperia Silicon Junction, Single, 215 mA, 2-Pin 100 V SOD-882 BAS16LD,315
Technical Document
Specifications
Brand
NexperiaDiode Configuration
Single
Product Type
Silicon Junction
Maximum Forward Current If
215mA
Mount Type
Surface
Sub Type
Silicon Junction
Package Type
SOD-882
Pin Count
2
Maximum Power Dissipation Pd
250mW
Peak Reverse Recovery Time trr
4ns
Minimum Operating Temperature
-55°C
Peak Non-Repetitive Forward Surge Current Ifsm
4A
Maximum Peak Reverse Repetitive Voltage Vrrm
100V
Maximum Forward Voltage Vf
1.25V
Maximum Operating Temperature
150°C
Width
0.65 mm
Height
0.4mm
Standards/Approvals
No
Series
BAS16LD
Length
1.05mm
Automotive Standard
No
Product details
Small Signal Switching Diodes, Nexperia
Features
Supports customised high density circuit designs
Low-leakage and high-voltage types available
High switching speeds
Low capacitance
Diodes and Rectifiers
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
€ 3.69
€ 0.046 Each (Supplied as a Tape) (Exc. VAT)
Standard
80
€ 3.69
€ 0.046 Each (Supplied as a Tape) (Exc. VAT)
Stock information temporarily unavailable.
Standard
80
| Quantity | Unit price | Per Tape |
|---|---|---|
| 80 - 80 | € 0.046 | € 3.69 |
| 160 - 320 | € 0.044 | € 3.51 |
| 400 - 720 | € 0.032 | € 2.58 |
| 800 - 1520 | € 0.031 | € 2.49 |
| 1600+ | € 0.028 | € 2.22 |
