Nexperia, Logic Level Translator Translating Buffer 3 Voltage, 5-Pin TSSOP
Technical Document
Specifications
Brand
NexperiaDirection Type
Uni-Directional
Logic Family
AUP
Product Type
Logic Level Translator
Maximum Propagation Delay Time @ CL
25.9ns
Mount Type
Surface
Package Type
TSSOP
Number of Elements per Chip
3
Output Type
Single Ended
Pin Count
5
Logic Function
Translating Buffer
Maximum Low Level Output Current
4mA
Minimum Supply Voltage
1.1V
Maximum High Level Output Current
-4mA
Translation
Voltage
Maximum Supply Voltage
3.6V
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
125°C
Standards/Approvals
No
Series
74AUP1T34
Width
1.35 mm
Height
1mm
Length
2.25mm
Automotive Standard
No
Country of Origin
Malaysia
Product details
74AUP1G/74AUP2G/74AUP1T Family, Nexperia
74AUP Family
Industry-standard Advanced Ultra-low Power (AUP) logic family products for ultra-low power consumption, small footprint logic solutions for use in 1.8 V and mixed 1.8 V / 3.3 V circuit applications. The AUP logic family offers the following features:
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
€ 321.10
€ 0.107 Each (On a Reel of 3000) (Exc. VAT)
3000
€ 321.10
€ 0.107 Each (On a Reel of 3000) (Exc. VAT)
Stock information temporarily unavailable.
3000
