Murata Power Solutions OKL-T/3-W12 DC/DC Converter, 0.59V dc, 6 V dc/ 3 A, 12V dc Input, 4.5V, Through Hole, 85 °C Max
Technical Document
Specifications
Product Type
DC/DC Converter
Output Voltage 1
0.59, 6V dc
Maximum Input Voltage
12V dc
Minimum Input Voltage
4.5V
Mount Type
Through Hole
MTBF
12230400h
Number of Outputs
1
Ripple and Noise
25mV Pk-Pk
Output Voltage Adjustment Range
0.591/6 V
Output Current 1
3A
Package Type
SIP
Maximum Output Power
15W
Depth
16.5mm
Length
10.4mm
Weight
2g
Standards/Approvals
RoHS
Width
5.6mm
Series
OKL-T/3-W12
Efficiency
93%
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
85°C
Product details
Murata 3A Single Output Regulated Non-Isolated DC-DC Converter - OKR Series
Non-isolated (PoL) module
Wide input voltage range
Up to 3A output current
Adjustable output voltage via external resistors
Output ON/OFF inhibit
Output voltage sense
Over temperature and over current protection
SIP through hole package
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
€ 7.68
€ 7.68 Each (Exc. VAT)
Standard
1
€ 7.68
€ 7.68 Each (Exc. VAT)
Stock information temporarily unavailable.
Standard
1
| Quantity | Unit price |
|---|---|
| 1 - 4 | € 7.68 |
| 5 - 9 | € 7.45 |
| 10 - 24 | € 7.22 |
| 25 - 49 | € 6.99 |
| 50+ | € 6.77 |
