Molex KK 396 Series Right Angle Through Hole Pin Header, 10 Contact(s), 3.96 mm Pitch, 1 Row, Unshrouded
Technical Document
Specifications
Brand
MolexSeries
KK 396
Product Type
Pin Header
Pitch
3.96mm
Current
7A
Number of Contacts
10
Housing Material
Polyester
Number of Rows
1
Orientation
Right Angle
Shrouded/Unshrouded
Unshrouded
Connector System
Wire-to-Board
Mount Type
Through Hole
Contact Material
Phosphor Bronze
Contact Plating
Tin
Minimum Operating Temperature
-40°C
Row Pitch
3.96mm
Termination Type
Solder
Contact Gender
Male
Maximum Operating Temperature
105°C
Standards/Approvals
No
Voltage
250 V
Product details
90 Headers, 41792 Series
Mates with 2139; 3069; 6442 and 41695 Series housings and 2145 and 41815 Series PC Board connectors.
3.96mm Molex KK Range
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
€ 15.65
€ 1.565 Each (In a Pack of 10) (Exc. VAT)
Standard
10
€ 15.65
€ 1.565 Each (In a Pack of 10) (Exc. VAT)
Stock information temporarily unavailable.
Standard
10
| Quantity | Unit price | Per Pack |
|---|---|---|
| 10 - 40 | € 1.565 | € 15.65 |
| 50 - 90 | € 1.431 | € 14.31 |
| 100+ | € 1.295 | € 12.95 |
