MEAN WELL DR Switch Mode DIN Rail Power Supply, 85 → 264V ac ac Input, 12V dc dc Output, 3.5A Output, 45W
Technical Document
Specifications
Brand
Mean WellSeries
DR
Type
Switch Mode
Electrical Phase
1
Number of Outputs
1
AC or DC Input Voltage
ac
Input Voltage
85 → 264V ac
AC or DC Output Voltage
dc
Output Voltage
12V dc
Output Current
3.5A
Dimensions
93 x 78 x 67mm
Height
78mm
Width
93mm
Depth
67mm
MTBF
364600h
Maximum Temperature
+50°C
Mounting Type
DIN Rail Mount
Ripple And Noise
200mV Pk-Pk
Output Voltage Adjustment Range
10.8 → 13.2V
Special Features
Overvoltage and Short Circuit Protection
Standards Met
RoHS Compliant, TUV EN 60950-1, UL 508
Minimum Temperature
-10°C
Load Regulation
±1%
Product details
DR-45 Series Single Output Power Supply
A range of single phase DIN Rail power supplies from Mean Well with a fanless design and wattages available between 45 W and 480 W.
Features and Benefits
• Universal AC input/full range
• Protections: Short circuit/Overload/Over voltage/Over temperature
• Cooling by free air convection
• Can be installed on DIN Rail TS-35/7.5 or 15
• UL 508 (industrial control equipment) approved
• LED indicator for power-on
• 100% full load burn-in test
• Fix switching at 100 kHz
• 3 years warranty
Product Application Information
The units are suitable for powering security and building automation controls which are increasingly required in commercial and residential premises.
Approvals
UL508
