Technical Document
Specifications
Brand
LovatoProduct Type
Contactor
Coil Voltage
230V ac
Number of Poles
3
Contact Voltage
440V ac
Power Rating
4kW
Series
BF
Mount Type
DIN Rail
Normal State Configuration
3 NO
Number of Auxiliary Contacts
1
Auxiliary Contact Configuration
1 NO
Terminal Type
Screw
Operational Current Ie
9A
Minimum Operating Temperature
-50°C
Maximum Operating Temperature
70°C
Depth
81mm
Length
81mm
Standards/Approvals
IEC/EN 60947-4-1
Width
45mm
Pole and Throw Configuration
3P
Country of Origin
Italy
Product details
3-pole contactors, 9 to 50A in AC3 duty
AC or DC auxiliary supply
Highly conductive auxiliary contacts
Easy mounting on a 35mm DIN rail
IP20 finger safety to prevent touching of live parts
The front cover, fixed between the breaker and contactor, provide protection to the connection
