IXYS 2200V 120A, Dual Rectifier Diode, 3-Pin TO-240AA MDD95-22N1B
Technical Document
Specifications
Brand
IXYSMounting Type
Panel Mount
Package Type
TO-240AA
Maximum Continuous Forward Current
120A
Peak Reverse Repetitive Voltage
2200V
Diode Configuration
Series
Rectifier Type
High Voltage
Diode Type
Rectifier
Pin Count
3
Maximum Forward Voltage Drop
1.43V
Number of Elements per Chip
2
Diode Technology
Silicon Junction
Product details
MDD Series Dual Diode Modules, Ixys
Approvals
UL recognised component
Diodes and Rectifiers, Ixys
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
€ 44.08
€ 44.08 Each (Exc. VAT)
1
€ 44.08
€ 44.08 Each (Exc. VAT)
Stock information temporarily unavailable.
1
Stock information temporarily unavailable.
| Quantity | Unit price |
|---|---|
| 1 - 1 | € 44.08 |
| 2 - 9 | € 42.32 |
| 10 - 19 | € 40.99 |
| 20 - 24 | € 39.68 |
| 25+ | € 38.80 |
