HARWIN, M22-30 Female Connector Housing, 2mm Pitch, 16 Way, 2 Row

RS Stock No.: 842-848Brand: HARWINManufacturers Part No.: M22-3020800
brand-logo
View all in Wire Housings & Plugs

Technical Document

Specifications

Brand

HARWIN

Number Of Contacts

16

Number Of Rows

2

Pitch

2mm

Gender

Female

Series

M22-30

For Use With

M22 Series Connector

Body Orientation

Straight

Length

15.4mm

Width

4.1mm

Housing Material

Nylon

Country of Origin

Taiwan, Province Of China

Product details

Socket Housings

Single and double row crimp socket shells which mate with 2mm pitch headers.

M22-301 Series SIL housings mate with M22-201/203 Series headers typical stock nos. 681-3287 respectively
Shells accept crimp terminals stock nos. 547-3245 (tin plate) or 547-3289 (gold plate)
