HARTING D-Sub 26 Way Right Angle 2.29 mm Pitch Through Hole D-Sub Connector, with 4 to 40 UNC Screw Lock Female
Technical Document
Specifications
Brand
HartingNumber of Contacts
26
Product Type
D-Sub Connector
Orientation
Right Angle
Current
2A
Mount Type
Through Hole
Connector Gender
Female
Connector Type D
D-Sub
Mounting Hardware
4 to 40 UNC Screw Lock
D-Sub Shell Size
DS-2
Housing Material
Steel
Voltage
1 kV
Minimum Operating Temperature
-55°C
Termination Type
Solder
Contact Gender
Female
Maximum Operating Temperature
105°C
Standards/Approvals
No
Contact Material
Copper Alloy
Contact Plating
Gold
Series
D-Sub
Pitch
2.29mm
Product details
Stamped solder pins, angled with grounding board locks
High density
Metal or Steel shell
Performance levels 3
Harting D Sub High Density
The high density range exceeds the contact capacity of a standard subminiature D connector by 70%.
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
€ 6.74
€ 6.74 Each (Exc. VAT)
Standard
1
€ 6.74
€ 6.74 Each (Exc. VAT)
Stock information temporarily unavailable.
Standard
1
| Quantity | Unit price |
|---|---|
| 1 - 9 | € 6.74 |
| 10 - 49 | € 6.50 |
| 50+ | € 5.62 |
