Finder 48 Series Interface Relay, DIN Rail Mount, 110V ac Coil, DPDT, 2-Pole
Technical Document
Specifications
Brand
FinderCoil Voltage
110V ac
Contact Configuration
DPDT
Mounting Type
DIN Rail
Series
48 Series
Number of Poles
2
Terminal Type
Screw
Switching Voltage
250V
Depth
75.3mm
Height
78.6mm
Length
15.8mm
Contact Material
Silver Alloy
Input Current
10.1mA
Life
10000000 cycles
Operating Temperature Range
-40 → +70°C
Turn Off Time
12ms
Turn On Time
15ms
Dimensions
15.8 x 75.3 x 78.6mm
Standards Met
CE, EAC
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
+70°C
Country of Origin
Italy
Product details
48 Series
Finder 48 series relay interface modules are an ideal interface for PLC and electronic systems.
Features and Benefits
Contact resistance: 50mΩ
Mechanical life: AC versions; 10 x 106 operations, DC versions; 20 x 106 operations
Dimensions: H78.6mm, W15.8mm, D76mm
Instant ejection of relay using plastic retaining clip
Supply status indication and EMC coil suppression module
Push-in and screw terminals
Replacement relays stock no. 351-572 etc are available (Finder 40 Series), and should be selected such that the coil voltage, contact configuration and rating match the original type
Approvals
BBJ; BEAB; CSA; DEMKO; FIMKO; GOST; NEMKO; RINA; SEMKO; SEV; UL recognised component for Canada; VDE
Stock information temporarily unavailable.
€ 25.91
€ 25.91 Each (Exc. VAT)
1
€ 25.91
€ 25.91 Each (Exc. VAT)
Stock information temporarily unavailable.
1
| Quantity | Unit price |
|---|---|
| 1 - 4 | € 25.91 |
| 5 - 9 | € 25.10 |
| 10+ | € 24.02 |
