Technical Document
Specifications
Brand
EpcosProduct Type
Pulse Transformer
Primary Inductance
3mH
Primary DC Resistance
23Ω
Turns Ratio
1 : 1 :8.42
Mount Type
Surface
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
125°C
Maximum Operating Frequency
300kHz
Length
7.6mm
Depth
7.10mm
Standards/Approvals
RoHS, AEC-Q200
Width
8.8mm
Series
EP6
Minimum Operating Frequency
50kHz
Isolation Voltage
200Vrms
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
£ 38.00
£ 38.00 Each (Exc. VAT)
1
£ 38.00
£ 38.00 Each (Exc. VAT)
Stock information temporarily unavailable.
1
| Quantity | Unit price |
|---|---|
| 1 - 4 | £ 38.00 |
| 5+ | £ 37.24 |
