EPCOS B32522 Polyester Film Capacitor, 63 V ac, 100 V dc, ±10%, 1μF, Through Hole
Technical Document
Specifications
Brand
EpcosCapacitance
1µF
Voltage
63 V ac, 100 V dc
Mounting Type
Through Hole
Tolerance
±10%
Series
B32522
Lead Pitch
15mm
Length
18mm
Depth
5mm
Height
10.5mm
Dimensions
5 x 10.5 x 18mm
Dielectric
Polyester
Terminal Type
Through Hole
Lead Diameter
0.8mm
Maximum Operating Temperature
+125°C
Minimum Operating Temperature
-55°C
Product details
MKT Series
Construction
Dielectric: Polyethylene Terephthalate (Polyester)
Layer technology available in 5, 7.5, 10, 15, 22.5 and 27.5 mm pitch
Plastic case (UL 94 V-0)
Epoxy resin sealing
Features
High pulse strength
High contact reliability
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
€ 0.70
€ 0.70 Each (Exc. VAT)
Standard
1
€ 0.70
€ 0.70 Each (Exc. VAT)
Stock information temporarily unavailable.
Standard
1
Stock information temporarily unavailable.
| Quantity | Unit price |
|---|---|
| 1 - 24 | € 0.70 |
| 25 - 49 | € 0.42 |
| 50 - 99 | € 0.36 |
| 100 - 249 | € 0.33 |
| 250+ | € 0.31 |
