Brad from Molex Right Angle Female 4 way M8 to Unterminated Sensor Actuator Cable, 2m
Technical Document
Specifications
Brand
Brad from MolexSeries
Nano-Change
Cross Sectional Area
0.25 mm²
Number of Cores
4
Sheath Material
PVC
Sheath Colour
Black
Length
2m
Connector 1 Gender
Female
Connector 1
M8
Connector 1 Orientation
Right Angle
Connector 1 Number of Contacts
4
Connector 2
Unterminated
Coding
A
Shielded/Unshielded
Unshielded
Current Rating
3 A
Voltage Rating
60 V ac, 75 V dc
IP Rating
IP67
Maximum Operating Temperature
+80°C
American Wire Gauge
24 AWG
Connector 1 Housing Gender
Female
Operating Temperature Range
-25 → +80 °C
Minimum Operating Temperature
-25°C
Conductor Material
Copper Alloy
Country of Origin
Poland
Product details
Single Ended Leads
These 2m leads are available in 3, 4 or 8 way versions with a straight or right angle head incorporating an M8 anti-vibration coupling nut. There is a choice of PVC cable, for general purpose applications, or high-flex PUR cable, for extra chemical resistance (typically to oil based products) or continuous flexing applications where cable durability is required.
Brad Harrison - M8
The Brad Harrison® range of connectors and splitter boxes have been principally designed for use in industrial applications. The Quick Disconnect® principle offers cost savings by enabling quick and simple replacement of either the sensors or cable, helping keep machine down time to a minimum. Designed for use in harsh environments, these connectors are available in re-wireable or pre-wired, factory moulded versions which are robust, compact and waterproof up to IP68. They are typically used for control system products such as proximity, limit and other forms of switches, but are equally at home in test, instrumentation and other electrical/electronic applications where the operating environment is less arduous.
€ 6.77
€ 6.77 Each (Exc. VAT)
1
€ 6.77
€ 6.77 Each (Exc. VAT)
Stock information temporarily unavailable.
1
Stock information temporarily unavailable.
| Quantity | Unit price |
|---|---|
| 1 - 4 | € 6.77 |
| 5 - 24 | € 6.46 |
| 25 - 49 | € 6.09 |
| 50+ | € 5.77 |
